High strength C17000 alloy beryllium copper plate wear resistance

Overview of High-Strength C17000 Alloy Beryllium Copper Plate

The C17000 alloy beryllium copper plate is a precision alloy material renowned for its outstanding high strength. Through a unique precipitation hardening heat treatment process, it achieves mechanical properties far exceeding those of ordinary bronze. The high strength of this alloy is specifically manifested in extremely high yield strength, hardness, and excellent fatigue resistance, enabling it to maintain a stable form and resist deformation even when subjected to heavy loads and repeated stresses.
In terms of product shape, the C17000 beryllium copper is mainly supplied in forms such as sheets and strips. It can be precisely slit or cut according to customer requirements, offering a variety of thickness and width options to meet the processing needs of complex and precise parts.
This high-strength characteristic makes it an ideal choice for manufacturing plastic mold inserts, safety springs, high-load bearings and aerospace components, ensuring the durability and reliability of the products in extreme environments. The C17000 alloy beryllium copper plate is a key material in the industrial sector that strives for ultimate strength and performance.

Product specifications: Φ5.0 * 1000mm

Tensile strength (MPa): ≤ 1000

Yield strength (MPa): ≤ 1035

Thermal conductivity (%): ≤ 105

Elastic modulus (GPa): 128

Hardness before quenching (HV): 200 - 250

Quenching temperature (℃): 315 - 600

Processing method: Machining

The high strength and wear resistance of the C17000 alloy beryllium copper plate

The tensile strength in the aged state can reach 1100-1400 MPa, the yield strength is 900-1200 MPa, and the hardness is HRC 35-42, approaching the level of high-strength steel while maintaining the corrosion resistance of copper alloys.

The high-strength C17000 alloy beryllium copper plate has excellent mechanical properties, integrating physical and chemical properties. After heat treatment (solution treatment and aging treatment), the high-strength C17000 alloy beryllium copper plate possesses the same high strength limit, elastic limit, yield limit and fatigue limit as special steel, while also having high electrical conductivity, thermal conductivity, high hardness, corrosion resistance, wear resistance, good casting performance, non-magnetic property and spark-free impact characteristics. It is widely used in industries such as mold manufacturing, machinery, and electronics.

The high-strength C17000 alloy beryllium copper plate has no sand holes or pores, uniform hardness, dense structure, high strength, good thermal conductivity, good electrical conductivity, corrosion resistance, wear resistance, good processing performance under high pressure conditions, stable performance under high pressure, non-magnetic property, good polishing performance, good anti-adhesion performance.

Applications of high-strength C17000 alloy beryllium copper plate

Injection molds and high-pressure blow molding molds, mold inserts, rapid cooling, aluminum alloy mold inserts, increasing strength, wear resistance and shortening injection cycle, heat flow channel nozzles, electrodes and punch materials, non-magnetic molds, non-magnetic tools, high thermal conductivity bearings, capable of manufacturing surfaces with high precision mirror finish.
